DOUBLE ECCENTRIC HIGH PERFORMANCE BUTTERFLY VALVE
WESTAD SCORPIO 2X™ is designed for full shut-off and throttling services.
After more than 120 years of valve manufacturing, KLINGER Westad has designed a valve for special applications that will perform under extreme conditions.
KEY FEATURES
- DEVELOPED FOR USE IN LPG/LEG-, CHEMICAL-, OIL-, SEA WATER SYSTEMS ETC.
- DOUBLE ECCENTRIC DESIGN TO REDUCE WEAR ON SEAT
- BI-DIRECTIONAL AT FULL PRESSURE RATING
- FREE ACCESS TO STUFFING BOX AND GLAND
- SHAFT EXTENSIONS AVAILABLE
- FIRE SAFE ACC. TO API 607
SPECIFICATIONS
Temperature range: -110°C to +200°C
Pressure range: 25/50 bar
Flange standards: ANSI Class 150/300, PN10/16/25/40/50, JIS 10K/16K
Standard size range: 3″ (DN 80) – 40″ (DN 1000) Other sizes on request
End connection: Wafer, Lugged and Double Flanged
WESTAD SCORPIO 2X™ fulfills NORSOK L-001 requirements
MATERIALS
| Body: | Stainless Steel, Duplex, Superduplex, Ni-Al-Bronze, Cast Steel, Titanium |
| Disc: | Stainless Steel, Duplex, Superduplex, Ni-Al-Bronze, Titanium |
| Shaft: | Stainless Steel, Duplex, Superduplex, Monel, Titanium |
| Sealing: | PTFE (Spring-energized) – Fire safe |
WAFER TYPE
LUG TYPE
DOUBLE FLANGED TYPE
